TGPS-W9124GT-M12X-BP2-WV-IP54

Description

ORing’s Transporter^TM series managed Gigabit PoE Ethernet switches are designed for industrial waterproof applications, such as rolling stock, vehicle, and railway applications.  TGPS-W9124GT-M12X-BP2-WV-IP54 is a managed Redundant Ring Ethernet switch with 12x10/100/1000Base-T(X) P.S.E. and 4x10/100/1000Base-T(X) ports, which is specifically designed for the toughest and fully compliant with EN50155 requirements.  The switch supports Ethernet Redundancy protocol, O-Ring (recovery time < 30ms over 250 units of connection), O-Chain, MRP, and MSTP/RSTP/STP (IEEE 802.1s/w/D). It can protect your mission-critical applications from network interruptions or temporary malfunctions with its fast recovery technology.  TGPS-W9124GT-M12X-BP2-WV-IP54 also supports Power over Ethernet, a system that transmits electrical power of up to 30 watts, along with data, to remote devices over standard twisted-pair cable in an Ethernet network.  Each TGPS-W9124GT-M12X-BP2-WV-IP54 switch features 12 10/100B/1000Base-T(X) P.S.E. (Power Sourcing Equipment) ports.  P.S.E. is a device (switch or hub, for instance) that will provide power in a PoE connection.  TGPS-W9124GT-M12X-BP2-WV-IP54 includes 2 sets of bypass ports that protect the network from failures and Network maintenance by ensuring network integrity during power loss.  And support wide operating temperature from -40^oC to 75^oC.  TGPS-W9124GT-M12X-BP2-WV-IP54 can also be managed centrally and conveniently by Open-Vision, except the Web-based interface, Telnet, and console (CLI) configuration.  Therefore, the switch is one of the most reliable choices for EN50155 waterproof, highly-managed Gigabit Ethernet applications.

Features

• Leading EN50155-compliant Ethernet switch for rolling stock application
• Developed according to IEC 62443-4-1 and compliant with the IEC 62443-4-2 industrial cybersecurity standards.
• Support O-Ring (recovery time < 30ms over 250 units of connection) and MSTP (RSTP/STP compatible) for Ethernet Redundancy
• O-Chain allows multiple redundant network rings
• Supports standard IEC 62439-2 MRP (Media Redundancy Protocol) function
• Supports standard ITU-T G.8032 ERPS v1/v2 for Ethernet Redundancy
• Supports IEEE 802.3af/at compliant PoE with a maximum 15.4/30Watts per port
• Supports PoE scheduled configuration and PoE auto-ping check function
• Supports isolated power protection
• Supports IEEE 1588v2 clock synchronization
• Supports IPV6 new Internet Protocol version
• Supports Modbus TCP protocol
• Supports IEEE 802.3az Energy-Efficient Ethernet technology
• Provided HTTPS/SSH protocol to enhance network security
• Supports IP-based bandwidth management
• Supports application-based QoS management
• Supports Device Binding security function
• Supports DOS/DDOS auto prevention
• IGMP v2/v3 (IGMP snooping support) for filtering multicast traffic
• Supports SNMP v1/v2c/v3 & RMON & 802.1Q VLAN Network Management
• Supports ACL, TACACS+, and 802.1x User Authentication for security
• Supports 9.6K Bytes Jumbo Frame
• Multiple notifications for warning of an unexpected event
• Web-based, Telnet, Console (CLI), and Windows utility (Open-Vision) configuration
• Supports LLDP Protocol
• Supports S3 level power interrupt protection.
• Supports isolated power protection included
• Wall mounting enabled
• Supports IP-54 grade waterproof design
