IGPS-1042GPA

商品介紹

IGPS-1042GPA is a slim type unmanaged PoE switch with P.S.E. function. IGPS-1042GPA supports Power over Ethernet, a system to transmit electrical power, along with data, to remote devices over standard twisted-pair cable in an Ethernet network.

IGPS-1042GPA has 4x 10/100/1000Base-T(X) P.S.E. (Power Sourcing Equipment) ports, and 2x 100/1000Base-X SFP port. The SFP port optical network speed can be set by changing the settings of the DIP-Switch below. IGPS-1042GPA supports wide range 50~57VDC power inputs and generates 50VDC P.S.E. power output per port. P.S.E. is a device (switch or hub for instance) that will provide power in a PoE setup. The wide operating temperature range from -40°C to 75°C can satisfy most of operating environment. Therefore, the switch is one of the most reliable choices for PoE Ethernet application.

產品特色

•  4x 10/100/1000Base-T(X) PoE ports and 2x 100/1000Base-X SFP socket
•  Supports P.S.E. based on IEEE 802.3at standard
•  Supports store and forward transmission
•  Supports flow control
•  Rigid IP-30 housing design
•  DIN-Rail and wall mounting enabled
•  Supports Jumbo Frame up to 10K Bytes
